概述
線性回歸 (Linear Regression) 是利用回歸分析來確定兩種或兩種以上變量間相互依賴的定量關系.
對線性回歸還不是很了解的同學可以看一下這篇文章:
python深度總結線性回歸
MSE
均方誤差 (Mean Square Error): 是用來描述連續誤差的一種方法. 公式:
y_predict: 我們預測的值y_real: 真實值
線性回歸
公式
w: weight, 權重系數
b: bias, 偏置頂
x: 特征值
y: 預測值
梯度下降
梯度下降 (Gradient Descent) 是一種優化算法. 參數會沿著梯度相反的方向前進, 以實現損失函數 (loss function) 的最小化.
計算公式:
w: weight, 權重參數
w': 更新后的 weight
lr : learning rate, 學習率
dloss/dw: 損失函數對 w 求導
w: weight, 權重參數
w': 更新后的 weight
lr : learning rate, 學習率
dloss/dw: 損失函數對 b 求導
線性回歸實現
計算 MSE
def calculate_MSE(w, b, points):
"""
計算誤差MSE
:param w: weight, 權重
:param b: bias, 偏置頂
:param points: 數據
:return: 返回MSE (Mean Square Error)
"""
total_error = 0 # 存放總誤差, 初始化為0
# 遍歷數據
for i in range(len(points)):
# 取出x, y
x = points.iloc[i, 0] # 第一列
y = points.iloc[i, 1] # 第二列
# 計算MSE
total_error += (y - (w * x + b)) ** 2 # 計總誤差
MSE = total_error / len(points) # 計算平均誤差
# 返回MSE
return MSE
梯度下降
def step_gradient(index, w_current, b_current, points, learning_rate=0.0001):
"""
計算梯度下降, 跟新權重
:param index: 現行迭代編號
:param w_current: weight, 權重
:param b_current: bias, 偏置頂
:param points: 數據
:param learning_rate: lr, 學習率 (默認值: 0.0001)
:return: 返回跟新過后的參數數組
"""
b_gradient = 0 # b的導, 初始化為0
w_gradient = 0 # w的導, 初始化為0
N = len(points) # 數據長度
# 遍歷數據
for i in range(len(points)):
# 取出x, y
x = points.iloc[i, 0] # 第一列
y = points.iloc[i, 1] # 第二列
# 計算w的導, w的導 = 2x(wx+b-y)
w_gradient += (2 / N) * x * ((w_current * x + b_current) - y)
# 計算b的導, b的導 = 2(wx+b-y)
b_gradient += (2 / N) * ((w_current * x + b_current) - y)
# 跟新w和b
w_new = w_current - (learning_rate * w_gradient) # 下降導數*學習率
b_new = b_current - (learning_rate * b_gradient) # 下降導數*學習率
# 每迭代10次, 調試輸出
if index % 10 == 0:
print("This is the {}th iterations w = {}, b = {}, error = {}"
.format(index, w_new, b_new,
calculate_MSE(w_new, b_new, points)))
# 返回更新后的權重和偏置頂
return [w_new, b_new]
迭代訓練
def runner(w_start, b_start, points, learning_rate, num_iterations):
"""
迭代訓練
:param w_start: 初始weight
:param b_start: 初始bias
:param points: 數據
:param learning_rate: 學習率
:param num_iterations: 迭代次數
:return: 訓練好的權重和偏執頂
"""
# 定義w_end, b_end, 存放返回權重
w_end = w_start
b_end = b_start
# 更新權重
for i in range(1, num_iterations + 1):
w_end, b_end = step_gradient(i, w_end, b_end, points, learning_rate)
# 返回訓練好的b, w
return [w_end, b_end]
主函數
def run():
"""
主函數
:return: 無返回值
"""
# 讀取數據
data = pd.read_csv("data.csv")
# 定義超參數
learning_rate = 0.00001 # 學習率
w_initial = 0 # 權重初始化
b_initial = 0 # 偏置頂初始化
w_end = 0 # 存放返回結果
b_end = 0 # 存放返回結果
num_interations = 200 # 迭代次數
# 調試輸出初始誤差
print("Starting gradient descent at w = {}, b = {}, error = {}"
.format(w_initial, b_initial, calculate_MSE(w_initial, b_initial, data)))
print("Running...")
# 得到訓練好的值
w_end, b_end = runner(w_initial, b_initial, data, learning_rate, num_interations, )
# 調試輸出訓練后的誤差
print("\nAfter {} iterations w = {}, b = {}, error = {}"
.format(num_interations, w_end, b_end, calculate_MSE(w_end, b_end, data)))
完整代碼
import pandas as pd
import tensorflow as tf
def run():
"""
主函數
:return: 無返回值
"""
# 讀取數據
data = pd.read_csv("data.csv")
# 定義超參數
learning_rate = 0.00001 # 學習率
w_initial = 0 # 權重初始化
b_initial = 0 # 偏置頂初始化
w_end = 0 # 存放返回結果
b_end = 0 # 存放返回結果
num_interations = 200 # 迭代次數
# 調試輸出初始誤差
print("Starting gradient descent at w = {}, b = {}, error = {}"
.format(w_initial, b_initial, calculate_MSE(w_initial, b_initial, data)))
print("Running...")
# 得到訓練好的值
w_end, b_end = runner(w_initial, b_initial, data, learning_rate, num_interations, )
# 調試輸出訓練后的誤差
print("\nAfter {} iterations w = {}, b = {}, error = {}"
.format(num_interations, w_end, b_end, calculate_MSE(w_end, b_end, data)))
def calculate_MSE(w, b, points):
"""
計算誤差MSE
:param w: weight, 權重
:param b: bias, 偏置頂
:param points: 數據
:return: 返回MSE (Mean Square Error)
"""
total_error = 0 # 存放總誤差, 初始化為0
# 遍歷數據
for i in range(len(points)):
# 取出x, y
x = points.iloc[i, 0] # 第一列
y = points.iloc[i, 1] # 第二列
# 計算MSE
total_error += (y - (w * x + b)) ** 2 # 計總誤差
MSE = total_error / len(points) # 計算平均誤差
# 返回MSE
return MSE
def step_gradient(index, w_current, b_current, points, learning_rate=0.0001):
"""
計算梯度下降, 跟新權重
:param index: 現行迭代編號
:param w_current: weight, 權重
:param b_current: bias, 偏置頂
:param points: 數據
:param learning_rate: lr, 學習率 (默認值: 0.0001)
:return: 返回跟新過后的參數數組
"""
b_gradient = 0 # b的導, 初始化為0
w_gradient = 0 # w的導, 初始化為0
N = len(points) # 數據長度
# 遍歷數據
for i in range(len(points)):
# 取出x, y
x = points.iloc[i, 0] # 第一列
y = points.iloc[i, 1] # 第二列
# 計算w的導, w的導 = 2x(wx+b-y)
w_gradient += (2 / N) * x * ((w_current * x + b_current) - y)
# 計算b的導, b的導 = 2(wx+b-y)
b_gradient += (2 / N) * ((w_current * x + b_current) - y)
# 跟新w和b
w_new = w_current - (learning_rate * w_gradient) # 下降導數*學習率
b_new = b_current - (learning_rate * b_gradient) # 下降導數*學習率
# 每迭代10次, 調試輸出
if index % 10 == 0:
print("This is the {}th iterations w = {}, b = {}, error = {}"
.format(index, w_new, b_new,
calculate_MSE(w_new, b_new, points)))
# 返回更新后的權重和偏置頂
return [w_new, b_new]
def runner(w_start, b_start, points, learning_rate, num_iterations):
"""
迭代訓練
:param w_start: 初始weight
:param b_start: 初始bias
:param points: 數據
:param learning_rate: 學習率
:param num_iterations: 迭代次數
:return: 訓練好的權重和偏執頂
"""
# 定義w_end, b_end, 存放返回權重
w_end = w_start
b_end = b_start
# 更新權重
for i in range(1, num_iterations + 1):
w_end, b_end = step_gradient(i, w_end, b_end, points, learning_rate)
# 返回訓練好的b, w
return [w_end, b_end]
if __name__ == "__main__": # 判斷是否為直接運行
# 執行主函數
run()
輸出結果:
Starting gradient descent at w = 0, b = 0, error = 5611.166153823905
Running...
This is the 10th iterations w = 0.5954939346814911, b = 0.011748797759247776, error = 2077.4540105037636
This is the 20th iterations w = 0.9515563561471605, b = 0.018802975867006404, error = 814.0851271130122
This is the 30th iterations w = 1.1644557718428263, b = 0.023050105300353223, error = 362.4068500146176
This is the 40th iterations w = 1.291753898278705, b = 0.02561881917471017, error = 200.92329896151622
This is the 50th iterations w = 1.3678685455519075, b = 0.027183959773995233, error = 143.18984477036037
This is the 60th iterations w = 1.4133791147591803, b = 0.02814903475888354, error = 122.54901023376003
This is the 70th iterations w = 1.4405906232245687, b = 0.028755312994862656, error = 115.16948797045545
This is the 80th iterations w = 1.4568605956220553, b = 0.029147056093611835, error = 112.53113537539161
This is the 90th iterations w = 1.4665883081088924, b = 0.029410522232548166, error = 111.58784050644537
This is the 100th iterations w = 1.4724042147529013, b = 0.029597287663210802, error = 111.25056079777497
This is the 110th iterations w = 1.475881139890538, b = 0.029738191313600983, error = 111.12994295811941
This is the 120th iterations w = 1.477959520545057, b = 0.02985167266801462, error = 111.08678583026905
This is the 130th iterations w = 1.479201671130221, b = 0.029948757225817496, error = 111.07132237076124
This is the 140th iterations w = 1.4799438156483897, b = 0.03003603745100295, error = 111.06575992136905
This is the 150th iterations w = 1.480386992125614, b = 0.030117455167888288, error = 111.06373727064113
This is the 160th iterations w = 1.4806514069946144, b = 0.030195367306897165, error = 111.0629801653088
This is the 170th iterations w = 1.4808089351476725, b = 0.030271183144693698, error = 111.06267551686379
This is the 180th iterations w = 1.4809025526554018, b = 0.030345745328433527, error = 111.0625326308038
This is the 190th iterations w = 1.4809579561496398, b = 0.030419557701150367, error = 111.0624475783524
This is the 200th iterations w = 1.480990510387525, b = 0.030492921525124016, error = 111.06238320300855
This is the 210th iterations w = 1.4810094024003952, b = 0.030566016933760057, error = 111.06232622062124
This is the 220th iterations w = 1.4810201253791957, b = 0.030638951634017437, error = 111.0622718818556
This is the 230th iterations w = 1.4810259638611891, b = 0.030711790026994222, error = 111.06221848873447
This is the 240th iterations w = 1.481028881765914, b = 0.030784570619965538, error = 111.06216543419914
This is the 250th iterations w = 1.4810300533774932, b = 0.030857316437543122, error = 111.06211250121454
This is the 260th iterations w = 1.4810301808342632, b = 0.03093004124680784, error = 111.06205961218657
This is the 270th iterations w = 1.4810296839649824, b = 0.031002753279495907, error = 111.06200673937376
This is the 280th iterations w = 1.4810288137973704, b = 0.031075457457601333, error = 111.06195387285815
This is the 290th iterations w = 1.48102772042814, b = 0.031148156724127858, error = 111.06190100909376
This is the 300th iterations w = 1.4810264936044433, b = 0.03122085283878386, error = 111.06184814681296
This is the 310th iterations w = 1.4810251869886903, b = 0.0312935468537513, error = 111.06179528556238
This is the 320th iterations w = 1.4810238326671836, b = 0.031366239398161695, error = 111.0617424251801
This is the 330th iterations w = 1.4810224498252484, b = 0.031438930848192506, error = 111.06168956560795
This is the 340th iterations w = 1.481021049934344, b = 0.03151162142877266, error = 111.06163670682551
This is the 350th iterations w = 1.4810196398535866, b = 0.03158431127439525, error = 111.06158384882504
This is the 360th iterations w = 1.4810182236842395, b = 0.03165700046547913, error = 111.0615309916041
This is the 370th iterations w = 1.4810168038785667, b = 0.031729689050110664, error = 111.06147813516172
This is the 380th iterations w = 1.4810153819028469, b = 0.03180237705704362, error = 111.06142527949757
This is the 390th iterations w = 1.48101395863381, b = 0.03187506450347233, error = 111.06137242461139
This is the 400th iterations w = 1.48101253459568, b = 0.03194775139967933, error = 111.06131957050317
This is the 410th iterations w = 1.4810111101019028, b = 0.03202043775181446, error = 111.06126671717288
This is the 420th iterations w = 1.4810096853398989, b = 0.032093123563556446, error = 111.06121386462064
This is the 430th iterations w = 1.4810082604217312, b = 0.032165808837106485, error = 111.06116101284626
This is the 440th iterations w = 1.481006835414406, b = 0.03223849357378233, error = 111.06110816184975
This is the 450th iterations w = 1.4810054103579875, b = 0.03231117777437349, error = 111.06105531163115
This is the 460th iterations w = 1.4810039852764323, b = 0.0323838614393536, error = 111.06100246219052
This is the 470th iterations w = 1.4810025601840635, b = 0.032456544569007456, error = 111.0609496135277
This is the 480th iterations w = 1.4810011350894463, b = 0.03252922716350693, error = 111.06089676564281
This is the 490th iterations w = 1.4809997099977015, b = 0.032601909222956374, error = 111.06084391853577
This is the 500th iterations w = 1.4809982849118903, b = 0.032674590747419754, error = 111.0607910722065
After 500 iterations w = 1.4809982849118903, b = 0.032674590747419754, error = 111.0607910722065
到此這篇關于詳解TensorFlow2實現線性回歸的文章就介紹到這了,更多相關TensorFlow2線性回歸內容請搜索腳本之家以前的文章或繼續瀏覽下面的相關文章希望大家以后多多支持腳本之家！
